CT Orbiter H Pulley

Triple pulley with mobile side plates, very versatile and robust.

Main features:

• It allow the insertion of two connectors in the upper eyelet and it is mounted on ball bearings
• The light-alloy flanges extend beyond the pulley wheels to minimise rope wear
• Ideal for constructing rescue winches with 6x reduction factor or in multiple pulley systems where a larger lifting force is required
• Additional attachment point suitable for a single connector
• For use with Ø ≤13 mm ropes

Specifications:

• Max lifetime: 30 years
• Minimum tensile strength: 45kN
• WLL: 12kN
• 96% efficiency
• EN 12278:2007, UIAA 127
